- Rated Current : On/Off Status : 25mA, 24VDC
- Rated Current : Under Infrequent On/Off State : 100mA, 50VDC
- Contact Resistance : 100 mΩ / Min. at 500 VDC
- Withstand Voltage : 500 VAC / 1 Minute
- Pull Force : 1000g / MAx
- Pull Stroke : 0.9mm
- Mechanical Life : 5000 Cycles (Min.)
- Electrical Life : 2000 Cycles/25mA, 24VDC
- Use Temperature : -20°C ~ 70°C
- Storage Temperature : -40°C ~ 85°C
- Material (Top Cover) : Thermoplastic UL 94V-0 rate, Black
- Material (Base) : Thermoplastic UL 94V-0 rate, Black
- Material (Push Button) : Thermoplastic UL 94V-0 rate, White
- Material (Contact) : Phosphor Bronze, Gold Plated
100 Pc(s) In Stock
SKU
DAM-08-I.L.S
Spectra DAM-08-I.L.S 8 Way DIP I.C Type SMD Switch
₹26.00
For 1 Pc(s)
- DAM-08-I.L.S
- 85365090
- SMT
- 8
- Pc(s)
- Yes
- GST 18%
- China
Product Specification
Datasheet
