100 Pc(s) In Stock
SKU
DAM-06-I.L.T

Spectra DAM-06-I.L.T 6 Way DIP I.C Type PCB Straight Switch

₹24.00 For 1 Pc(s)
( Price exclusive of GST )
Request For Higher Quantity Quotation
  • DAM-06-I.L.T
  • 85365090
  • PCB Straight
  • 6
  • Pc(s)
  • Yes
  • GST 18%
  • China
Product Specification
  • Rated Current : On/Off Status : 25mA, 24VDC
  • Rated Current : Under Infrequent On/Off State : 100mA, 50VDC
  • Contact Resistance : 100 mΩ / Min. at 500 VDC
  • Withstand Voltage : 500 VAC / 1 Minute
  • Pull Force : 1000g / MAx
  • Pull Stroke : 0.9mm
  • Mechanical Life : 5000 Cycles (Min.)
  • Electrical Life : 2000 Cycles/25mA, 24VDC
  • Use Temperature : -20°C ~ 70°C
  • Storage Temperature : -40°C ~ 85°C
  • Material (Top Cover) : Thermoplastic UL 94V-0 rate, Black
  • Material (Base) : Thermoplastic UL 94V-0 rate, Black
  • Material (Push Button) : Thermoplastic UL 94V-0 rate, White
  • Material (Contact) : Phosphor Bronze, Gold Plated
Datasheet
