Phoenix Contact Printed-Circuit Board Connector - FKC 2,5/ 4-ST-5,08

₹94.43

Product Overview

SKU 1873074
HSN Code 85366990
UOM Pc(s)
Manufacturer Phoenix Contact
Net weight in grams 6.8
ROHS Compliance No
Tax GST 18%
Country of Origin Germany

Product Specification

Number of positions : 4
Maximum load current : 12 A
Rated voltage (II/2) : 630 V
Rated voltage (III/2) : 320 V
Nominal current IN : 12 A
Nominal cross section : 2.5 mm²
Connection method : Push-in spring connection
Recommended crimping tool : 1212034 CRIMPFOX 6
ferrules without insulating collar, according to DIN 46228‑1 : Cross section: 0.5 mm²; Length: 8 mm ... 10 mm
Contact material : Cu alloy
Housing color : Green
Insulating material : PA
Flammability rating according to UL 94 : V0

Product Details

PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, number of potentials: 4, Number of rows: 1, Number of positions per row: 4, number of connections: 4, product range: FKC 2,5/..-ST, pitch: 5.08 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 0 °, Locking clip: - Locking clip, plug-in system: CLASSIC COMBICON, Locking: without, mounting: without, type of packaging: packed in cardboard
