Phoenix Contact PCB header - MC 1,5/ 2-G-5,08

₹30.78

Product Overview

SKU 1836189
HSN Code 85366930
UOM Pc(s)
Manufacturer Phoenix Contact
Net weight in grams 0.7
ROHS Compliance No
Tax GST 18%
Country of Origin Germany

Product Specification

Number of connections : 2
Number of connections : 2
Number of rows : 1
Maximum load current : 8 A
Contact material : Cu alloy
Surface characteristics : Tin-plated
Metal surface terminal point (top layer) : Tin (3 - 5 µm Sn)
Metal surface contact area (middle layer) : Nickel (1 - 3 µm Ni)
Metal surface soldering area (top layer) : Tin (3 - 5 µm Sn)
Metal surface soldering area (middle layer) : Nickel (1 - 3 µm Ni)
Housing color : green (6021)
Insulating material : PBT
Product Category : Pluggable Terminal Blocks
Product : Headers
Pitch : 5.08 mm

Product Details

PCB headers, nominal cross section: 1.5 mm2, color: green, nominal current: 8 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, number of potentials: 2, Number of rows: 1, Number of positions per row: 2, number of connections: 2, product range: MC 1,5/..-G, pitch: 5.08 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.4 mm, plug-in system: MINI COMBICON, Pin connector pattern alignment: Standard, Locking: without, mounting: without, type of packaging: packed in cardboard
