- Number of positions : 6
- Number of Levels : 1
- Pitch : 0.150" (3.81mm)
- Header Orientation : 90°, Right Angle
- Termination Style : Solder
- Mounting Type : Through Hole
- Current – IEC : 8A
- Voltage – IEC : 250 V
- Material Flammability Rating : UL94 V-0
- Color : Green
- Contact Mating Finish : Tin
- Housing Material : Polybutylene Terephthalate (PBT)
- 1803316
- 85366930
- Pc(s)
- Phoenix Contact
- 1.72
- No
- GST 18%
- India
Product Specification
Product Details
PCB headers, nominal cross section: 1.5 mm2, color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, number of potentials: 6, number of rows: 1, number of positions: 6, number of connections: 6, product range: MC 1,5/..-G, pitch: 3.81 mm, screw head form: L Slotted, pin layout: Linear pinning, solder pin [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: COMBICON MC 1,5, Pin connector pattern alignment: Standard, locking: without, mounting: without, type of packaging: packed in cardboard
