32 Pc(s) In Stock
SKU
1803293

Phoenix Contact Printed-Circuit Board Connector - MC 1,5/ 4-G-3,81

₹16.47 For 1 Pc(s)
( Price exclusive of GST )
Request For Higher Quantity Quotation
  • 1803293
  • 85366930
  • Pc(s)
  • Phoenix Contact
  • 1.1
  • No
  • GST 18%
  • India
Product Details
PCB headers, nominal cross section: 1.5 mm2, color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, number of potentials: 4, Number of rows: 1, Number of positions per row: 4, number of connections: 4, product range: MC 1,5/..-G, pitch: 3.81 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.4 mm, plug-in system: MINI COMBICON, Pin connector pattern alignment: Standard, Locking: without, mounting: without, type of packaging: packed in cardboard
Product Specification
  • Number of connections : 4
  • Number of connections : 4
  • Number of rows : 1
  • Maximum load current : 8 A
  • Contact material : Cu alloy
  • Surface characteristics : Tin-plated
  • Metal surface terminal point (top layer) : Tin (3 - 5 µm Sn)
  • Metal surface contact area (middle layer) : Nickel (1 - 3 µm Ni)
  • Metal surface soldering area (top layer) : Tin (3 - 5 µm Sn)
  • Metal surface soldering area (middle layer) : Nickel (1 - 3 µm Ni)
  • Housing color : green (6021)
  • Insulating material : PBT
  • Flammability rating according to UL 94 : V0
  • Product Category : Pluggable Terminal Blocks
  • Product : Headers
