Out of stock
SKU
1792249

Phoenix Contact PCB connector - MVSTBR 2,5/ 2-ST-5,08

₹21.67 For 1 Pc(s)
  • 1792249
  • 85366990
  • Pc(s)
  • Phoenix Contact
  • 4.366
  • No
  • GST 18%
  • India
Product Details
PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, number of potentials: 2, number of rows: 1, number of positions: 2, number of connections: 2, product range: MVSTBR 2,5/..-ST, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 90 °, locking clip: - Locking clip, plug-in system: COMBICON MSTB 2,5, locking: without, mounting: without, type of packaging: packed in cardboard
Product Specification
  • Number of positions : 2
  • Number of Levels : 1
  • Pitch : 0.200" (5.08mm)
  • Plug Wire Entry : 90°
  • Termination Style : Screw - Rising Cage Clamp
  • Mounting Type : Free Hanging (In-Line)
  • Current – IEC : 12A
  • Voltage – IEC : 630 V
  • Wire Gauge or Range – mm² : 0.2-2.5mm²
  • Color : Green
  • Features : Retention Latches (Wire Side)
  • Torque – Screw : 0.5-0.6 Nm (4.4-5.3 Lb-In)
