62 Pc(s) In Stock
SKU
1786187

Phoenix Contact Printed-Circuit Board Connector - IC 2,5/ 3-ST-5,08

₹167.18 For 1 Pc(s)
( Price exclusive of GST )
Request For Higher Quantity Quotation
  • 1786187
  • 85366990
  • Pc(s)
  • Phoenix Contact
  • 5.1
  • No
  • GST 18%
  • Germany
Product Details
PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, number of potentials: 3, Number of rows: 1, Number of positions per row: 3, number of connections: 3, product range: IC 2,5/..-ST, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, Locking clip: - without locking clip, plug-in system: CLASSIC COMBICON, Locking: without, mounting: without, type of packaging: packed in cardboard
Product Specification
  • Number of Positions : 3
  • Number of connections : 3
  • Number of rows : 1
  • Maximum load current : 12 A
  • Product Category : Pluggable Terminal Blocks
  • Product : Plugs - Inverted
  • Pitch : 5.08 mm
  • Contact Material : Copper
  • Contact Plating : Tin
  • Flammability Rating : UL 94 V-0
  • Housing Material : Polyamide (PA)
  • Height : 15 mm
  • Length : 19.2 mm
  • Width : 16.74 mm
