- Number of positions : 5
- Number of connections : 5
- Number of rows : 1
- Maximum load current : 12 A
- Nominal cross section : 2.5 mm²
- Type of contact : Female connector
- Conductor cross section solid : 0.2 mm² ... 2.5 mm²
- Contact material : Cu alloy
- Surface characteristics : hot-dip tin-plated
- Metal surface terminal point (top layer) : Tin (5 - 7 µm Sn)
- Metal surface contact area (top layer) : Tin (5 - 7 µm Sn)
- Housing color : green (6021)
- Insulating material : PA
- Flammability rating according to UL 94 : V0
- Product Category : Pluggable Terminal Blocks
28 Pc(s) In Stock
SKU
1766916
Phoenix Contact Printed-Circuit Board Connector - GMSTB 2,5/ 5-ST
₹155.03
For 1 Pc(s)
- 1766916
- 85366990
- Pc(s)
- Phoenix Contact
- 9.3
- No
- GST 18%
- Germany
Product Details
PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Female connector, number of potentials: 5, Number of rows: 1, Number of positions per row: 5, number of connections: 5, product range: GMSTB 2,5/..-ST, pitch: 7.5 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, Locking clip: - Locking clip, plug-in system: CLASSIC COMBICON, Locking: without, mounting: without, type of packaging: packed in cardboard
