Phoenix Contact PCB header - GMSTB 2,5/ 5-G

₹37.30 For 1 Pc(s)

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

SKU 1766042
HSN Code 85366930
UOM Pc(s)
Manufacturer Phoenix Contact
Net weight in grams 2.5
ROHS Compliance No
Tax GST 18%
Country of Origin Germany

Product Details

PCB headers, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Male connector, number of potentials: 5, Number of rows: 1, Number of positions per row: 5, number of connections: 5, product range: GMSTB 2,5/..-G, pitch: 7.5 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.5 mm, plug-in system: CLASSIC COMBICON, Pin connector pattern alignment: Standard, Locking: without, mounting: without, type of packaging: packed in cardboard

Product Specification

Number of positions : 5
Number of connections : 5
Number of rows : 1
Maximum load current : 12 A
Contact material : Cu alloy
Surface characteristics : Tin-plated
Metal surface contact area (top layer) : Tin (3 - 5 µm Sn)
Metal surface contact area (middle layer) : Nickel (1.3 - 3 µm Ni)
Metal surface soldering area (top layer) : Tin (3 - 5 µm Sn)
Metal surface soldering area (middle layer) : Nickel (1.3 - 3 µm Ni)
Housing color : green (6021)
Insulating material : PA
Product Category : Pluggable Terminal Blocks
Product : Headers
Pitch : 7.5 mm
