Out of stock
SKU
1757048

Phoenix Contact PCB connector - MSTB 2,5/ 5-ST-5,08

₹54.89 For 1 Pc(s)
  • 1757048
  • 85366990
  • Pc(s)
  • Phoenix Contact
  • 8.603
  • No
  • GST 18%
  • India
Product Details
PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, number of potentials: 5, number of rows: 1, number of positions: 5, number of connections: 5, product range: MSTB 2,5/..-ST, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0 °, locking clip: - Locking clip, plug-in system: COMBICON MSTB 2,5, locking: without, mounting: without, type of packaging: packed in cardboard
Product Specification
  • Number of Levels : 1
  • Positions Per Level : 5
  • Pitch : 0.200" (5.08mm)
  • Current – IEC : 12A
  • Voltage – IEC : 630 V
  • Termination Style : Screw - Rising Cage Clamp
  • Plug Wire Entry : 180°
  • Mounting Type : Free Hanging (In-Line)
  • Voltage – UL : 300 V
  • Color : Green
  • Contact Mating Finish : Tin
  • Screw Size : M3
