Belden 6 Fiber - Central Tube - Glass Yarn/Steel Wire - Armored/Single PE Jacket

₹80.00 For 1 Mtr(s)

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Product Overview

SKU BAGU50QA006BK
HSN Code 85444999
Reel Length Cut Length Available
Manufacturer Belden
UOM Mtr(s)
ROHS Compliance Yes
Tax GST 18%
Country of Origin India

Product Details

6 optical fibers, Central gel filling loose tubes, Flexible non-metallic strength member - glass yarn, two rip cords, CSTA armor, Two Steel Wires Embedded in Single PE jacket (black)

Product Specification

Number of Fiber : 6
Buffer Tube Material : PBT - Polybutylene Terephthalate
Buffer Tube Filling Material : Synthetic Thixotropic Gel
Strength Member Material : Glass yarn, Two Steel Wire Embedded in Sheath
Armor Type : Corrugated
Armor Material : Steel Tape
Outer Jacket Material : PE - Polyethylene
Overall Nominal Diameter : 8.7 mm
Mode : OM2
Max. Tensile Force : 2000 N
Specification : IEC 60794-1
EU RoHS Compliant (Y/N) : Y
Bulk Cable Weight : 85 kg/km

Datasheet

Belden-BAGUxxQA.pdf
